DIN 1481 Spring Type Straight Heavy Duty Pin
Product Description:
| Product name | Spring Type Straight Heavy Duty Pin |
| Size | M1-10 |
| Material | 50Mn/65Mn |
| Surface treatment | Black/Zinc |
| Standard | DIN |
| Certificate | ISO 9001 |
| Sample | Free Samples |
Usage:
Made of spring steel, longitudinally slit and quenched round tube. With its high elasticity, it is evenly squeezed into the pin hole, which is firm and reliable. The requirements for the accuracy and surface roughness of the pin hole are low, and they can be assembled and disassembled multiple times, but the stiffness is poor. Suitable for occasions with shock and vibration. Not suitable for positioning with high accuracy requirements.
Elastic cylindrical pin, also known as spring pin, is a hollow cylindrical body with no head. It is axially slotted and chamfered at the ends of both ends. It is used for positioning, connection, and fixing between parts. Shear force, the outer diameter of this pin is slightly larger than the assembly hole diameter
Product advantages:
- Precision Machining
☆ Measure and process using precision machine tools and measuring tools under strictly controlled environmental conditions.
- High-quality carbon steel(35#/45#)
☆ With long life, low heat generation, high hardness, high rigidity, low noise, high wear resistance and other characteristics.
- Cost-effective
☆ The use of high-quality carbon steel steel, after precision processing and forming, greatly improves the user experience.
Surface treatment:
- BLACK
☆ Black is a common method for metal heat treatment. The principle is to make an oxide film on the metal surface to isolate the air and achieve rust prevention. Blackening is a common method for metal heat treatment. The principle is to make an oxide film on the metal surface to isolate the air and achieve rust prevention.
- ZINC
☆ Electro-galvanizing is a traditional metal coating treatment technology that provides basic corrosion resistance to metal surfaces. The main advantages are good solderability and suitable contact resistance. Due to its good lubrication properties, cadmium plating is commonly used in aviation, aerospace, marine, and radio and electronic products. The plating layer protects the steel substrate from both mechanical and chemical protection, so its corrosion resistance is much better than zinc plating.
Parameter Of Product:
OUR PACKAGE:
1. 25 kg bags or 50kg bags.
2. bags with pallet.
3. 25 kg cartons or cartons with pallet.
4. Packing as customers' request
